Part number Part name Qty
KP710-00150 Gasket – F. I. P 1
11026-01M02 Washer – drain plug 1
11044-05U16 Gasket – Cylinder head 1
11062-05U00 O ring - seal 3
11062-05U01 O ring - seal 2
11062-05U02 O ring - seal 4
12279-5L310 OIL SEAL – CRANKSHAFT REAR 1
13042-16V00 OIL SEAL - CAMSHAFT 2
13207-53F00 OIL SEAL - VALVE 12
13207-84A00 OIL SEAL - VALVE 12
13270-58S01 GASKET – ROCKER COVER EXHAUST 1
13270-58S11 GASKET – ROCKER COVER INTAKE 1
13510-10Y10 OIL SEAL - CRANKSHAFT 1
14035-05U10 GASKET – INTAKE MANIFOLD 1
14036-05U00 GASKET – TURBO CHARGER OUTLET 2
14465-05U11 GASKET – INLET TUBE 3
15053-1E400 GASKET – OIL STRAINER 1
15066-71L00 GASKET – OIL PUMP 1
15189-01P00 GASKET – EYE BOLT 2
15189-13C00 GASKET – EYE BOLT 2
15193-P9000 GASKET – EYE BOLT 6
15193-03E00 GASKET – EYE BOLT 12
15196-05U10 GASKET-OIL TURBO 1
15196-79E00 GASKET-TURBO CHARGER 2
15239-71L00 GASKET 1
16076-05U00 GASKET 1
16175-05U70 GASKET - ADAPTER 6
22131-58S10 O RING - SEAL 1
22636-N4200 GASKET-WATER TEMP 1
23785-40F00 GASKET-A. A. C VALVE 1
