- Артикул:
SC7464
- Производитель:
CP-Carrillo
Make Toyota / Lexus
Vehicle Model Supra MKIV
Model Supra TT MK4 93-98 JZA80, Supra NT MK4 93-98 JZA80, SC300/Soarer 92-00 Z30, IS300 01-05 XE10, GS300/Aristo 91-97 S140, GS300/Aristo 98-05 S160
Engine 2JZ-GE, 2JZ-GE VVTi, 2JZ-GTE, 2JZ-GTE VVTi
Rod Length 5.590" / 142mm
Rod Length Oversize Standard Length
Bore Diameter 86.5mm
Bore Oversize 0.020" / 0.5mm
Stroke 86mm (Standard Stroke)
Compression Ratio 9.0:1
Compression Ratio Range 8.0:1 - 9.0:1, 9.0:1 - 10.0:1
Pin Size 0.866" / 22mm
Upgraded Pin (not included) 866-2250-25CP3C
Included Ring Set CPN-3406
Included Pin Locks 866x063 SWL
Included Pin 866-2250-18CP1C
Head cc 45 cc
Dome cc -9.6 cc
Compression Height 1.338" / 34mm
Brand CP Pistons
Skirt Type Full Round
Piston Material 2618
Carb Legal Unspecified
Wrist Pin Wall Thickness 0.180"
Wrist Pin Dimensions .866" x 2.250" x .180"
Pin Material 5100 Chrome Moly Steel
